Hoverguard 600 Product Specs

Hoverguard 600 Product Specification

Hovercraft Payload (standard equipment): 600 lbs (272 kg)
Hull: 12'6" long x 6'6" wide (3.81 m x 1.98 m)
Choice of Hull Colors: RED/WHITE
Speed: 30 mph (48 kph) on calm water, 50 mph (80 kph) on smooth ice
Wave Handling Capacity: 1 - 2 ft (30-60 cms)
Turning Capability: 180 and 360 degree turns on land, ice, and water
　

Hoverguard 600 Standard Equipment:

2-Cycle, 2-cylinder 60 HP air-cooled engine
High performance exhaust system
Dual carburetors with automatic oil-injection system
Exhaust gas temperature gauges
Two 6-gallon (22.7 L) portable fuel tanks with switch-over valve
Electric and recoil start
720 cold cranking amp, maintenance-free battery
36" (91 cms) fan driven through a 510H200 belt and crankshaft mounted pulley system
Removable fanguard and engine cover
Air-straighteners,four rudder steering system
"Front-first" lift air system with variable lift and thrust control
68 Hypalon® coated skirts and stainless steel skirt anchors
Heavy duty drag flap
Four replaceable hardened aluminum skid rails
Six foot long space on each side of the center console
Console mounted seat pad
One stowage pocket in front fascia
Two side-mounted 5' (1.5 m)grap rails
Two 8' (2.4 m) grapple poles
Two 20" (50 cm) ring buoys
Navigation/bow/strobe and twin 55 watt operating lights
One handheld 200,000 C.P spotlight
One duct-mounted amber strobe light (120 flashes/min)
Hourmeter
Tachometer
Light switches
16" (40 cms) windshield
Accessory power plug
Battery master switch
Lift and mooring eyes
Bilge pump

Options:

Salt water muffler
Non-standard base color
Dual signal horn
Crew protection windshield i.p.o 16 inch windshield
Removable rear cockpit vinyl enclosure
Combined siren and public address system
Two rear-mounted first aid stowage boxes
Hearing protection ear muffs, Thunder® T3
Mustang survival suits and vests

DIMENSIONS
Length:	(381 cms)
Width:	6'6" (198 cms)
Cockpit Length:	5'0" (1.5 m)
Cockpit Width:	4'6" (1.35 m)
Height:	64" (163 cms)
Approx Dry Weight:	700 lbs (318 kg)
ENGINE
Type:	2-cycle/2-cylinder
Capacity:	497 cc
Max. Horsepower:	60 HP
Max RPM:	7,200
Fuel Capacity:	12 US gal (45.4 l)
Battery:	525 cca
Ignition:	12 V CDI
Charging:	15 amp
Cooling:	Fan Air
Carburetor:	MIKUNI DUAL
THRUST SYSTEM
Fans:	Single Lift/Thrust
Fan Diameter:	36" (91.5 cms)
Variable Splitter:	CABLE
CUSHION
Max Hoverheight:	8" (20 cms)
# of Skirt Segments:	68
PERFORMANCE
Max Payload:	600 lbs (270 kg)
Speed Calm Water:	40 mph (48 km)
Speed Smooth Ice:	50 mph (80 km)
Cushion (hump) time w/ calm water & max load:	8 seconds
Max Wave Handling Capacity:	2 ft (60 cms)
Turning Capability	180º and 360º turns on land, ice & water

	Hoverguard 600	Hoverguard 700	Hoverguard 800	Hoverguard 1000
DIMENSIONS
Length:	12'6" (3.81 m)	14'6" (4.42 m)	16'0" (4.88 m)	19'3" (5.87 m)
Width:	6'6" (1.98 m)	6'6" (1.98 m)	8'0" (2.44 m)	8'0" (2.44 m)
Cockpit Length:	5'0" (1.5 m)	7'0" (2.13 m)	6'0" (1.8 m)	9'0" (2.75 m)
Cockpit Width:	4'6" (1.35 m)	4'6" (1.35 m)	5'0" (1.5 m)	5'0" (1.5 m)
Height:	64" (1.63 m)	64" (1.63 m)	80" (2.03 m)	80" (2.03 m)
Approx Dry Weight:	700 lbs (318 kg)	750 lbs (341 kg)	2,200 lbs (907 kg)	2,500 lbs (1,134 kg)
ENGINE
Type:	2-cycle/2-cylinder	2-cycle/2-cylinder	4-cycle/V-8	4-cycle/V-8
Capacity:	497 cc	597 cu. in. (4.3 l)	350 cu. in. (5.7 l)	350 cu. in. (5.7 l)
Max. Horsepower:	60 HP	100 HP	250 HP	250 HP
Max RPM	7,200	8,000	4,200	4, 200
Fuel Capacity:	12 US gal (45.4 l)	12 US gal (45.5 l)	40 US gal (150 l)	40 US gal (150 l)
Battery:	525 cca	525 cca	2 X 875 cca	2 X 875 cca
Ignition:	12 V CDI	12 V electronic	12 V electronic	12 V electronic
Charging:	15 amp	20 amp	90 amp	90 amp
Cooling:	Fan Air	Liquid	Liquid	Liquid
Carburetor:	MIKUNI DUAL	MIKUNI DUAL	Multi-port/fuel injection	Multi-port/fuel injection
THRUST SYSTEM
Fans:	Lift/Thrust	Lift/Thrust	Lift/Thrust	Lift/Thrust
Fan Diameter:	36" (91.5 cms)	36" (91.5 cms)	39" (99 cms)	39" (99 cms)
Variable Splitter:	CABLE	CABLE	HYDRAULIC	HYDRAULIC
CUSHION
Max Hoverheight:	8" (20 cms)	8" (20 cms)	12" (30 cms)	12" (30 cms)
# of Skirt Segments:	68	76	64	72
PERFORMANCE
Max Payload:	600 lbs (270 kg)	750 lbs (341 kg)	850 lbs (385 kg)	1,200 lbs (544 kg)
Speed Calm Water:	40 mph (48 km)	40 mph (64 km)	40 mph (56 km)	40 mph (64 km)
Speed Smooth Ice:	50 mph (80 km)	60 mph (96 km)	60 mph (96 km)	60 mph (96 km)
Cushion (Hump) Time w/ Calm Water & Max Load:	8 seconds	5 seconds	10 seconds	12 seconds
Max Wave Handling:	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)
Turning Capability	180º and 360º turns on land, ice, & water
