Hoverguard 600 Product Specs

Features and Options

Hovercraft Payload (standard equipment): 1,200 lbs (544 kg)
Hull: 19'3" long x 8' wide (5.87 m x 2.44 m)
Choice of Hull Colors: RED/WHITE
Speed: 40 mph (64 kph) on calm water, 60 mph (96 kph) on smooth ice
Max Wave Handling Capacity: 2 ft (60 cms)
Turning Capability: 180 and 360 degree turns on land, ice and water

Standard equipment:

General Motors 4-cycle, V8 multi-port, fuel injected engine
12v electrical system with 50 amp alternator
Dual 875 cca batteries with battery master switch giving OFF-1-BOTH-2 positions
Thrust system: Twin 39" (99 cms) ducted twelve blade fans driven by Goodyear Eagle^® Kevlar^® Vee-tooth cog belts; air straightener arrays; ten cable-operated air rudders and removable fanguards
Hydraulically controlled splitter plates with handle bar mounted electric push button switches allowing variable lift and thrust settings for speed and cushion control on the move
Integrated lift and thrust air system with Hypalon^® coated skirts, rear mounted drag flap, six hardened aluminum replaceable skid rails
Fiberglass bottom hull made of hand lay-up woven roving plus sealed polyurethane foam liner with high freeboard sides
Woven roving fiberglass inner hull with glossy gel coat finish
Flat non-skid cockpit floor 5' x 13' (1.5 m x 3.96 m) overall with 18" (45 cms) high cockpit sides
Two triangular vinyl cushion seats mounted one on each side of 4' (1.2 m) long centerline cushion crew seat and stowage module
Crew protection windshield comprising rigid fiberglass gel coat structure with large curved windshield, two side windows with short roof plus windshield wiper and washer system
Fast-reaction handle bar steering, twist grip throttle and two fuel gauges

Hinged access instrument panel with tachometer, hourmeter, engine oil pressure gauge, coolant temperature gauge, voltmeter
40 US gal (150 l) capacity fuel tanks
Four mooring eyes, one bow eye and one rear winching eye
Twin fiberglass tailfin style wave guards
Twin strobe flashers (red, blue or amber), all-round light on ducts and red/green bow light.
Two grab rails, two collapsible grapple poles, two ring buoys
Two 2,000 gph (7500 l/hr) bilge pumps

Options:

Stainless steel dual muffler
Removable vinyl cockpit enclosure
Combined siren and public address system
Heater-defroster
Heavy-duty lift eyes for raising craft with a hoist
90 AMP alternator (in place of 50)
Night rescue lighting package
Stationary hover system
Interior cockpit lighting
Aluminum decking over basic decking to withstand impact loads
All Kevlar^® bottom hull
Non-standard color
Thunder^® T3 Hearing protection
Mustang^® survival suits and vests
Special options available on request (GPS, radio and intercom equipment, special seating)

DIMENSIONS
Length:	19'3" (587 cms)
Width:	8'0" (244 cms)
Cockpit Length:	9'0" (2.75 m)
Cockpit Width:	5'0" (1.5 m)
Height:	80" (203 cms)
Approx. Dry Weight:	2,500 lbs. (1,134 kg)
ENGINE
Type:	General Motors 4-cycle/V-8
Capacity:	350 cu. in. (5.7 l)
Max. Horsepower:	250 HP
Max. R.P.M.	4,200
Fuel Capacity:	40 US gall (150 l)
Battery:	2 X 875 cca
Ignition:	12 V electronic
Charging:	90 amp
Cooling:	Liquid
Carburetor:	Multi-port/fuel injection
THRUST SYSTEM
Fans:	Dual Lift/Thrust
Fan Diameter:	39" (99 cms)
Variable Splitter:	HYDRAULIC
CUSHION
Max. Hoverheight:	12" (30 cms)
# of Skirt Segments:	72
PERFORMANCE
Max. Payload:	1,200 lbs. (544 kg)
Speed Calm Water:	40 mph (64 km)
Speed Smooth Ice:	60 mph (96 km)
Cushion (hump) time w/ calm water & max. load:	12 seconds
Wave Handling Cap.:	2 ft. (60 cms)
Turning Capability	180º and 360º turns on land, ice, & water

	Hoverguard 600	Hoverguard 700	Hoverguard 800	Hoverguard 1000
DIMENSIONS
Length:	12'6" (3.81 m)	14'6" (4.42 m)	16'0" (4.88 m)	19'3" (5.87 m)
Width:	6'6" (1.98 m)	6'6" (1.98 m)	8'0" (2.44 m)	8'0" (2.44 m)
Cockpit Length:	5'0" (1.5 m)	7'0" (2.13 m)	6'0" (1.8 m)	9'0" (2.75 m)
Cockpit Width:	4'6" (1.35 m)	4'6" (1.35 m)	5'0" (1.5 m)	5'0" (1.5 m)
Height:	64" (1.63 m)	64" (1.63 m)	80" (2.03 m)	80" (2.03 m)
Approx Dry Weight:	700 lbs (318 kg)	750 lbs (341 kg)	2,200 lbs (907 kg)	2,500 lbs (1,134 kg)
ENGINE
Type:	2-cycle/2-cylinder	2-cycle/2-cylinder	4-cycle/V-8	4-cycle/V-8
Capacity:	497 cc	597 cu. in. (4.3 l)	350 cu. in. (5.7 l)	350 cu. in. (5.7 l)
Max. Horsepower:	60 HP	100 HP	250 HP	250 HP
Max RPM	7,200	8,000	4,200	4, 200
Fuel Capacity:	12 US gal (45.4 l)	12 US gal (45.5 l)	40 US gal (150 l)	40 US gal (150 l)
Battery:	525 cca	525 cca	2 X 875 cca	2 X 875 cca
Ignition:	12 V CDI	12 V electronic	12 V electronic	12 V electronic
Charging:	15 amp	20 amp	90 amp	90 amp
Cooling:	Fan Air	Liquid	Liquid	Liquid
Carburetor:	MIKUNI DUAL	MIKUNI DUAL	Multi-port/fuel injection	Multi-port/fuel injection
THRUST SYSTEM
Fans:	Lift/Thrust	Lift/Thrust	Lift/Thrust	Lift/Thrust
Fan Diameter:	36" (91.5 cms)	36" (91.5 cms)	39" (99 cms)	39" (99 cms)
Variable Splitter:	CABLE	CABLE	HYDRAULIC	HYDRAULIC
CUSHION
Max Hoverheight:	8" (20 cms)	8" (20 cms)	12" (30 cms)	12" (30 cms)
# of Skirt Segments:	68	76	64	72
PERFORMANCE
Max Payload:	600 lbs (270 kg)	750 lbs (341 kg)	850 lbs (385 kg)	1,200 lbs (544 kg)
Speed Calm Water:	40 mph (48 km)	40 mph (64 km)	40 mph (56 km)	40 mph (64 km)
Speed Smooth Ice:	50 mph (80 km)	60 mph (96 km)	60 mph (96 km)	60 mph (96 km)
Cushion (Hump) Time w/ Calm Water & Max Load:	8 seconds	5 seconds	10 seconds	12 seconds
Max Wave Handling:	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)
Turning Capability	180º and 360º turns on land, ice, & water
