Hoverjet LC

Features and Options

Hovercraft Payload (standard equipment): 600 lbs (272 kg)
Hull: 12'6" long x 6'6" wide (3.81 m x 1.98 m)
Choice of Hull Colors: RED/WHITE/BLUE/YELLOW
Speed: 40 mph (64 kph) on calm water, 70 mph (112 kph) on smooth ice
Max Wave Handling Capacity: 2 ft (60 cms)
Turning Capability: 180 and 360 degree turns on land, ice and water
Standard equipment:
  • Two-cycle, two-cylinder 60 HP  air-cooled engine with high performance muffler
  • Electric and recoil start
  • Dual carburetors with automatic oil injection system
  • Exhaust gas temperature gauges
  • Tachometer
  • Two six gallon (22.7 l) portable plastic fuel tanks with switch-over valve
  • 12v maintenance-free battery
  • 36" (91 cms) 12-bladed fan driven through a 510H200 belt and crankshaft mounted pulley system
  • Removable fanguard and engine cover
  • Air-straighteners, four rudder steering system
  • "Front-first" lift air system
  • 68 Hypalon® coated skirts and stainless steel skirt anchors
  • Heavy duty drag flap
  • Four custom extruded replaceable, hardened aluminum skid rails
  • 16" (40 cms) windshield
  • Seating pad
  • Bilge pump
  • Two side mounted grab rails

Options:

  • Salt water muffler
  • Carburetor compensator Tempa-Flow
  • Navigation light package
  • Operating lights
  • Accessory socket
  • Stowage pocket
  • Lift eyes
  • Variable lift-thrust control
  • Dual signal horn
  • 720 cca maintenance-free battery
  • Crew protection windshield with wiper (in place of 16" windshield)
  • Removable vinyl cockpit enclosure
  • All Kevlar® bottom hull
  • Non-standard base color
  • Striping package
  • Thunder® T3 Hearing protection
  • Mustang® survival suits and vests



Technical Specifications


DIMENSIONS
Length: 12'6" (3.81 m)
Width: 6'6" (1.98 m)
Cockpit Length: 5'0" (1.50 m)
Cockpit Width: 4'6" (1.35 m)
Height over Strobe Light: 64" (1.63 m)
Approx. Dry Weight: 625 lbs (283 kg)
ENGINE
Type:  2-cycle/2-cylinder
Capacity: 497 cc
Max Horsepower: 60 HP
Max RPM: 7,000
Fuel Capacity: 6 US gal (22.7 l)
Battery: 300 cca
Ignition: 12 V CDI
Charging: 12.5 amp
Cooling: Fan Air
Carburetor: MIKUNI DUAL
THRUST SYSTEM SINGLE
Fans: Single Lift/Thrust
Fan Diameter: 36" (91.5 cms)
Variable Splitter: CABLE
CUSHION
Max Hoverheight: 8" (20 cms)
Skirt Segments: 68
PERFORMANCE
Max Payload: 600 lbs (272 kg)
Speed-Calm Water: 30 mph (48 km)
Speed-Smooth Ice: 50 mph (80 km)
Cushion (Hump) Time-Calm Water/Max Load: 8 seconds
Max Wave Handling: 2 ft (60 cms)
Turning Capability: 180º and 360º turns
