救災氣墊船

機器性能說明 :

Hovercraft Payload (standard equipment): 400 lbs (180 kg)
Hull: 10'6" long x 6'6" wide (3.2 m x 1.98 m)
Choice of Hull Colors: RED/WHITE/BLUE/YELLOW
Speed:40 mph (64 kph) on calm water, 70 mph (112 kph) on smooth ice
Max Wave Handling Capacity: 2 ft (60 cms)
Turning Capability: 180 and 360 degree turns on land, ice and water

Standard equipment:

Two-cycle, two-cylinder 60 HP air-cooled engine with high performance muffler
Electric and recoil start
Dual carburetors with automatic oil injection system
12v maintenance-free battery
Six gallon (22.7 l) portable plastic fuel tank
36" (91 cms) 12-bladed fan driven through a 510H200 belt and crankshaft mounted pulley system
Removable fanguard and engine cover
Air-straighteners, four rudder steering system
"Front-first" lift air system
60 Hypalon^® coated skirts and stainless steel skirt anchors
Heavy duty drag flap
Two custom extruded, replaceable hardened aluminum skid rails
16" (40 cms) windshield
Seating pad

Options:

Salt water muffler
Carburetor compensator Tempa-Flow
Navigation light package
Operating lights
Accessory socket
Stowage pocket
Lift eyes
Variable lift-thrust control
Two side mounted grab rails
Dual signal horn
Second 6 gal fuel tank and installation
720 cca maintenance-free battery
Crew protection windshield with wiper (in place of 16" windshield)
Removable vinyl cockpit enclosure
All Kevlar^® bottom hull
Non-standard base color
Striping package
Thunder^® T3 Hearing protection
Mustang^® survival suits and vests

DIMENSIONS
Length:	10'6" (3.20 m)
Width:	6'6" (1.98 m)
Cockpit Length:	3'6" (1.07 m)
Cockpit Width:	4'6" (1.35 m)
Height over Strobe Light:	64" (1.63 m)
Approx Dry Weight:	550 lbs (250 kg)
ENGINE
Type:	2-cycle/2-cylinder
Capacity:	497 cc
Max Horsepower:	60 HP
Max RPM:	7,000
Fuel Capacity:	6 US gal (22.7 l)
Battery:	300 cca
Ignition:	12 V CDI
Charging:	12.5 amp
Cooling:	Fan Air
Carburetor:	MIKUNI DUAL
THRUST SYSTEM
Fans:	Single Lift/Thrust
Fan Diameter:	36" (91.5 cms)
Variable Splitter:	CABLE (optionol)
CUSHION
Max Hoverheight:	8" (20 cms)
Skirt Segments:	60
PERFORMANCE
Max Payload:	400 lbs (181 kg)
Speed-Calm Water:	0 mph (64 km)
Speed-Smooth Ice:	60 mph (96 km)
Cushion (Hump) Time-Calm Water/Max Load:	5 seconds
Max Wave Handling:	2 ft (60 cms)
Turning:	180º and 360º turns

	Hoverjet GT	Hoverstar LC	Hoverstar Sportsman	Hovertour 700
DIMENSIONS
Length:	10'6" (3.20 m)	12'6" (3.81 m)	12'6" (3.81 m)	14'6" (4.42 m)
Width:	6'6" (1.98 m)	6'6" (1.98 m)	6'6" (1.98 m)	6'6" (1.98 m)
Cockpit Length:	3'6" (1.07 m)	5'0" (1.50 m)	5'0" (1.50 m)	7'0" (2.13 m)
Cockpit Width:	4'6" (1.35 m)	4'6" (1.35 m)	4'6" (1.35 m)	4'6" (1.35 m)
Height over Strobe Light:	64" (1.63 m)	64" (1.63 m)	64" (1.63 m)	64" (1.63 m)
Approx Dry Weight:	550 lbs (250 kg)	625 lbs (283 kg)	625 lbs (283 kg)	750 lbs (340 kg)
ENGINE
Type:	Rotax 2-cycle/2-cylinder
Capacity:	497 cc	497 cc	497 cc	597 cc
Max Horsepower:	60 HP	60 HP	60 HP	100HP
Max RPM	7,000	7,000	7,000	8,000
Fuel Capacity:	6 US gal (22.7 l)	12 US gal (45.4 l)	12 US gal (45.4 l)	12 US gal (45.4 l)
Battery:	300 cca	300 cca	300 cca	525 cca
Ignition:	12 V CDI	12 V CDI	12 V CDI	12 V CDI
Charging:	12.5 amp	12.5 amp	12.5 amp	24 amp
Cooling:	Fan Air	Fan Air	Fan Air	Liquid
Carburetor:	MIKUNI DUAL	MIKUNI DUAL	MIKUNI DUAL	MIKUNI DUAL
THRUST SYSTEM
Fans:	Single Fan Lift/Thrust
Fan Diameter:	36" (91.5 cms)
Variable Splitter:	CABLE (optional)	CABLE	CABLE	CABLE
CUSHION
Max Hoverheight:	8" (20 cms)	8" (20 cms)	8" (20 cms)	8" (20 cms)
Skirt Segments:	60	68	68	76
PERFORMANCE
Max Payload:	400 lbs (181 kg)	600 lbs (272 kg)	600 lbs (272 kg)	750 lbs (341 kg)
Speed-Calm Water:	40 mph (64 km)	30 mph (48 km)	30 mph (48 km)	40 mph (64 km)
Speed-Smooth Ice:	60 mph (96 km)	50 mph (80 km)	50 mph (80 km)	60 mph (96 km)
Cushion (Hump) Time-Calm Water/Max Load:	5 seconds	8 seconds	8 seconds	5 seconds
Max Wave Handling:	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)	2 ft (60 cms)
Turning:	180º and 360º turns
