• Ultra Wide: Wider distance between tie bar and clamping stroke with the usage of square platen. Suitable for larger variety of molds and capacitate in molding process.
• Ultra Durable: Increased durability through the application of new series toggle system upon Finite Element Analysis (FEA), high strength to increase lifespan of tie bars and assure quality of products.
• Ultra Clean: Usage of oil-less bearings on moving parts of platen and toggle boosts cleanliness and also helps to save on cleaning efforts and eliminate cost of lubricating oils. (HT-100I~HT-200I)
• Ultra Strong: All new high rigid structure frame, design upon Finite Element Analysis (FEA) of stress and strain affect. Assure the excellent of frame structure, the HT series were capable of this advantage improvement.
• Ultra Flexible: New frame structure comes with bigger product delivery space. This makes for installation of auxiliary equipments and is compatible with conveyors from multi direction to allow easier automation.
• Ultra Safe: Safety is enhanced by applying the exclusively designed non-adjusting safety bar and low-pressure protection loop.
• Ultra Intelligent: Equipped with the new FCS-2100 controller that has the capabilities for semi-close loop or close loop option, user-friendly graphic operation interface, online curve detection and centrally managed web link, this machine is ultra-smart!
• Ultra Save: Injection unit adapted with the patented regeneration loop. If Hi-Speed mode (Type I) is selected, it eliminates the consumption of oil return, and improves injection speed. When the Hi-pressure Mode (Type II) is selected, it permits higher injection pressure. This patented feature allows the same console to be operated for high injection speed products and high injection pressure products at the same time to significantly expand the applications of the console.
• Ultra Stable: Semi-close loop (above HT-600I) and high efficiency cooling system are more reliable in molding process.
• Ultra Easy: Easy nozzle alignment after injection carriage improved. Easy care and maintenance. Modularized power, hydraulic, mechanical components, easy care.

　

Items		Unit	HT-100I			HT-125I			HT-150I
Injection Unit
Screw Type		mm	A	B	C	A	B	C	A	B	C
Screw Diameter		mm	30	34	40	34	40	44	40	44	50
Screw Stroke		mm	150			180			200
Theoretical Shot Volume		cm³	108	139	192	163	226	273	251	301	388
Shot Weight of Injection(ps)		gram	99	128	175	144	200	240	205	250	322
Injection Pressure	I	kgf/cm²	1890	1475	1066	1938	1400	1157	1785	1481	1146
Injection Speed		mm/sec	134			120			116
Injection Rate		cm³/sec	95	122	168	109	151	182	146	176	228
Injection Pressure	II	kgf/cm²	2481	1932	1396	2471	1785	1475	2205	1822	1410
Injection Speed		mm/sec	103			95			95
Injection Rate		cm³/sec	73	93	129	86	119	144	119	144	186
Plasticizing Capacity(ps)		kg/hr	38	50	68	46	64	78	67	82	106
Screw Rotation Speed		rpm	250			205			210
Mould Clamping Unit
Mould Clamping Unit		tonf	100			125			150
Mould Clamping Stroke		mm	350			410			460
Dry Run Cycle		sec	1.8			1.8			1.8
Mould Thickness		mm	100-430			120-490			130-550
Suggested Minimum Mold Dim.(HxV)		mm	234x234			267x267			299x299
Distance Between Tie Bars(HxV)		mm	360x360			410x410			460x460
Mould Platen(HxV)		mm	525x525			600x600			670x670
Ejector Stroke		mm	90			100			110
Electrical Equipment
Pump Driving Motor		HP(kw)	15 (11.19)			20 (14.92)			25 (18.65)
Temperature Controller		(range) set	(0-400°C)x3			(0-400°C)x4			(0-400°C)x4
Heater Capacity		kw	5.57			7.1			9.94
Others
Machine Dimensions(LxWxH)		mm	4730x1280x1835			5000x1400x2000			5252x1400x2000
Oil Tank Capacity		liter	210			250			280
Machine Weight		metric tons	3.5			4.5			5.5
Max. System Pressure		kgf/cm²	140			140			140

*The shot weight is based on polystyrene at specific gravity of 1.05.
*Due to continuous improvements, we reserve the right to amend the above specifications without prior notice.
