The FT Series also comes with user-friendly microprocessor controller with these following features:

• Dust, oil proof and colorful touch switch control panel.
• El display of pressure, speed, time and distance for each motion.
• Shut-down device with 100 presets mold data memory.
• Equipped with 4 stages injection, 3 stages holding pressure and 3 stages back pressure.
• PID barrel temperature control: temperature abnormal & electrical wire disconnection alarm.
• SSR-solid state temperature controller.
• Screw cold start protection.
• Abnormal shot detection.
• Output quantity and packaging quantity preset.
• Clamping, injection and ejection (option), and carriage action (option) by linear potentiometer.
• Screw rotating speed read-out.
• Security code function to avoid missing data or careless changing.
• Super low pressure clamping ensures security of user, and maintains lifespan of machine efficiently.
• The FT Series is equipped with the following optional items:
  --Close loop system: to achieve high precision and stability.
  --Double loop system: to shorten the production cycle time.
  --High speed and high pressure injection system: for ultra thin products.
  --FCS-2100 microcomputer controller : It has excellent operating functions such as the ability to capacitate semi-close loop and close loop hydraulic system, plus personality graphic operation interface, curve on-line inspection function and central network connection management.

　

Item	Unit	FT-60			FT-90			FT-110			FT-140
Injection Unit
Screw diameter	mm	28	30	34	32	36	40	36	40	45	40	45	48
Injection pressure	kg/cm²	1857	1618	1260	2297	1815	1470	2204	1785	1410	2297	1815	1595
Theoretical shot volume	cm³	89	102	132	121	153	188	173	214	270	251	318	362
Shot weight of injection (ps)	gram	82	93	119	109	138	171	157	193	245	227	288	327
	ozs	2.9	3.3	4.2	3.8	4.8	6.0	5.5	6.8	8.6	8.0	10.1	11.5
Injection rate	cm³/sec	60	70	89	64	81	100	83	102	129	97	122	139
Plasticizing capacity (ps)	kg/hr	37	42	54	43	55	68	46	57	72	46	58	66
Screw rotation speed	rpm	210			210			195			158
Clamping Unit
Clamping force	metric tons	60			90			110			140
Clamping stroke	mm	270			300			350			380
Dry run cycle	sec	1.8			1.8			1.8			1.8
Mold thickness	mm	75-340			100-390			110-440			110-500
Suggested minimum mold dim.(HxV)	mm	210x170			230x195			255x220			275x240
Distance b/w tie bars	mm	320x260			350x300			390x340			420x370
Mold platen	mm	475x415			520x470			590x540			650x600
Ejector stroke	mm	70			80			90			100
Electrical Equipment
Pump driving motor	HP (kw)	10 (7.46)			15 (11.19)			15 (11.19)			20 (14.92)
Temperature controller	(range) set	(0-400°C)x3			(0-400°C)x3			(0-400°C)x4			(0-400°C)x4
Heater capacity	kw	3.9			5.1			6			8.4
Others
Machine dimensions.(LxWxH)	mm	3900x1000x1700			4350x1050x1760			4800x1100x1800			5300x1250x1924
Oil tank capacity	liter	135			190			230			260
Machine weight	metric tons	2.8			3.5			4.2			5.0
Pump pressure	kg/cm²	105			140			140			140

*The shot weight is based on polystyrene at specific gravity of 1.05.
*Due to continuous improvements, we reserve the right to amend the above specifications without prior notice.
