The FT Series also comes with user-friendly microprocessor controller with these following features:

• Dust, oil proof and colorful touch switch control panel.
• El display of pressure, speed, time and distance for each motion.
• Shut-down device with 100 presets mold data memory.
• Equipped with 4 stages injection, 3 stages holding pressure and 3 stages back pressure.
• PID barrel temperature control: temperature abnormal & electrical wire disconnection alarm.
• SSR-solid state temperature controller.
• Screw cold start protection.
• Abnormal shot detection.
• Output quantity and packaging quantity preset.
• Clamping, injection and ejection (option), and carriage action (option) by linear potentiometer.
• Screw rotating speed read-out.
• Security code function to avoid missing data or careless changing.
• Super low pressure clamping ensures security of user, and maintains lifespan of machine efficiently.
• The FT Series is equipped with the following optional items:
  --Close loop system: to achieve high precision and stability.
  --Double loop system: to shorten the production cycle time.
  --High speed and high pressure injection system: for ultra thin products.
  --FCS-2100 microcomputer controller : It has excellent operating functions such as the ability to capacitate semi-close loop and close loop hydraulic system, plus personality graphic operation interface, curve on-line inspection function and central network connection management.

　

Item	Unit	FT-320			FT-420			FT-520		FT-600
Injection Unit
Screw diameter	mm	70	75	80	70	75	80	80	85	85	90
Injection pressure	kg/cm²	1783	1553	1365	1851	1650	1450	1706	1511	1680	1500
Theoretical shot volume	cm³	1078	1237	1407	1116	1281	1457	1759	1986	2010	2226
Shot weight of injection (ps)	gram	975	1119	1273	1016	1166	1338	1592	1797	1820	2045
	ozs	34.2	39.3	44.7	36	41	47	55	60	63	72
Injection rate	cm³/sec	297	341	388	300	345	390	389	440	446	493
Plasticizing capacity (ps)	kg/hr	266	306	348	270	310	350	242	272	275	298
Screw rotation speed	rpm	126			138			114		130
Clamping Unit
Clamping force	metric tons	320			420			520		600
Clamping stroke	mm	600			670			800		900
Dry run cycle	sec	3.0			3.5			4		4.5
Mold thickness	mm	300-780			250-800			300-1000		300-1100
Suggested minimum mold dim.(HxV)	mm	420x360			460x400			525x525		560x560
Distance b/w tie bars	mm	650x550			715x615			810x810		860x860
Mold platen	mm	980x890			1075x975			1200x1200		1250x1250
Ejector stroke	mm	190			200			220		220
Electrical Equipment
Pump driving motor	HP (kw)	50(37.30)			50(37.30)			60(44.8)		75(56)
Temperature controller	(range) set	(0-400¢XC)x5			(0-400¢XC)x5			(0-400¢XC)x6		(0-400¢XC)x6
Heater capacity	kw	22.1			22.1			28.2		28.2
Others
Machine dimensions.(LxWxH)	mm	7200x1600x2200			7800x2000x2200			8500x2200x2680		10000x2200x2800
Oil tank capacity	liter	780			1000			1100		1100
Machine weight	metric tons	13.1			17.5			23		29.4
Pump pressure	kg/cm²	140			140			140		140

*The shot weight is based on polystyrene at specific gravity of 1.05.
*Due to continuous improvements, we reserve the right to amend the above specifications without prior notice.
