• Good hydraulic performance makes the operation smooth and the pipe vibration & noise lower so as to prolong the life of motor and pump.
• Equipped with the air cleaner and multi-spaced oil tank to ensure the clean pipes.
• New generation hydra-mech clamping system had obtained the patent in the R.O.C., Germany and Mainland China. Speed has been increased by 15%.
• Hydra-mech clamping system having the pressure compensation supplied by the high pressure cylinder while injection to ensure stable clamping force.
• Applying the FEA (Finite Element Analysis) to design the construction to reach the demand of high strength and fatigue-free.
• With our patented hydra-mech clamping system, there is no toggle problem, just accurate clamping force and a clamping unit that is easy to use and durable.

• Close loop system - To perform high precision and stability.
• Double loops system - To shorten the producing cycle time.
• High speed and high pressure injection system - For ultra thin products.
• FCS-2100 microcomputer controller : It has excellent operating functions such as the ability to capacitate semi-close loop and close loop hydraulic system, plus personality graphic operation interface, curve on-line inspection function and central network connection management.

　

Item	Unit	FT-1680		FT-2000		FT-2500		FT-3000
Injection Unit
Screw Diameter	mm	120	130	140	150	140	150	160	170
Injection Pressure	kg/cm²	1915	1632	1708	1488	1708	1488	1671	1480
Theoretical Shot Volume	cm³	8516	9995	11585	13299	11585	13299	18688	21097
Shot Weight of Injection (PS)	gram	7824	9043	10644	12218	10644	12218	16591	18731
	oz	275	320	375	430	375	430	584	659
Injection Rate	cm³/sec	862	1013	1174	1348	1174	1348	1421	1605
Plasticizing Capacity	kg/hr	699	839	973	1117	973	1117	1928	2178
Screw Rotation Speed	rpm	120		110		110		100
Clamping Unit
Clamping Force	metric tons	1680		2000		2500		3000
Clamping Strokes	mm	1600		1900		1900		2200
Mold Thickness	mm	500-1600		600-1700		600-1700		600-1830
Suggested Minimum Mold. Dim.(HxV)	mm	975x845		1170x1040		1170-1040		1300-1170
Distance Between Tie Bars	mm	1600x1300		1800x1600		1800-1600		2000-1800
Mold Platen	mm	2205x2005		2520x2320		2520-2320		2750-2550
Ejector Stroke	mm	270		300		300		330
Electrical Equipment
Pump Driving Motor	HP	200		225		232.5 (173.4)		257.5 (192)
Temperature Controller	(range) set	(0-400°C)x8		(0-400°C)x8		(0-400°C)x8		(0-400°C)x8
Heater Capacity	kw	76.8		81.6		81.6		123.2
Others
Machine Dimensions (LxWxH)	mm	17000x3200x 3300		19000x3500x 3500		19000x3500x 3500		20000x3700x 3700
Oil Tank Capacity	liter	2850		3000		3000		3400
Machine Weight	metric tons	113.4		150		180		240

*The shot weight is based on polystyrene at specific gravity of 1.05.
*Due to continuous improvements, we reserve the right to amend the above specifications without prior notice.
