BT GOLDPOWER equipped with new Highly efficient EURO Tier3-compliant
3-cylinder turbo, inter-cooler engines specified on the BT GOLDPOWER
models built MORE POWER AND MORE TORQUE and require LESS DIESEL, and
minimise Exhaust Emissions A product range combining performance,
reliability, comfort and design. This is the great strength of BT
GOLDPOWER tractors.
The BT GOLDPOWER series comes in three models and various variants
from 50 to 67 Engine HP that designed for specific applications :
» For
using in open field, For mowing, landscaping, tilling and
transport, nothing’s more versatile than a BT GOLDPOWER Series
tractors.
» MINIMAX
model (narrow orchard) with a reduced width, horizontal exhaust and
other features making it ideal for use in any confined space
applications, such as vineyards and orchards or for working inside
greenhouses and ideal for work in small-sized orchards.
» BAĞ-BAH聢E
(ORCHARD) model (orchard) ideal for work in standard orchards.
|
SPECIFICATION |
DESCRIPTION |
|
PERFORMANCE |
|
Rated Engine Power |
ISO /TR 14396
82 hp ISO ( 61 kW ) |
Max. Torgue@1400 rpm
Max. PTO Power @ rated |
294 Nm |
|
engine speed |
75.7 hp |
|
ENGINE |
|
Type |
Perkins / 1104A-44 |
|
No. Cylinders |
4 |
|
Injection |
Direct |
|
Capacity |
4.4 litre |
|
Air Cleaner |
Dual, Dry Air Cleaner with
overbonnet centrifugal
pre - cleaner / Oil bath air cleaner |
|
Exhaust |
Vertical |
|
ELECTRICS |
|
Alternator / Starter |
50A/ 3.0kW |
|
Lights |
Headlights,Sidelights,
brake lights, direction
indicators,rear work lamp |
|
Other |
Horn, 7- pin trailer socket |
|
CLUTCH |
|
Type |
Dual Clutch |
|
Diameter |
305 X 254 mm |
|
TRANSMISSION |
8 Forward 2 Reverse
Sliding Spur,
Optional:12x4 partly
synchromesh |
|
POWER TAKE OFF |
|
Type |
Dual Clucth, pedal operated |
|
PTO speed |
540 rev/ min @ 1685 engine rev / min or ground speedPTO |
|
Shaft Diameter |
35 mm ( 1.38 mm ) |
|
Number of Splines |
6 |
|
HYDRAULICS |
|
Functions |
Draft, Position, and
response control |
|
Max. Oil Flow |
16.7 litre / min |
|
Max.Pressure |
207 bar |
|
Max. Lift Capacity at linksends, link horizontal |
2290 kg |
|
Lower Links |
Cat 2 fixed ball ends
linkage check chains and
stabilisers |
|
Drawbar |
Swinging drawbar |
|
STEERING |
|
Type |
Manual /Hydrostatic |
|
REARAXLE AND BRAKES |
|
Brake Type |
Oil-Cooled, disc |
|
Actuation |
Mechanical, independent
or locked together |
|
Parking Brake |
Hand lever operated |
|
Differential Lock |
Mechanical actuation |
|
OPERATOR AREA |
|
Seat |
Spring Suspension |
|
Fender |
Flat Top |
|
Tool Box |
With optional toolkit |
|
INSTRUMENTATION |
|
Gauges |
Tachometer, fuel gauge,temperature gauge |
|
Warnings Lights |
Electric charge, low engine
oil presure, direction
indicators, main beam,
filter, (optional: 4WD, IPTO) |
|
STANDARDWHEELS AND TYRES |
Fronts - 2WD
- 4WD |
7.50 - 16
12.4 - 24 |
Rear - 2WD
- 4WD |
18.4 - 30
18.4 - 30
|
|
WEIGHTS AND DIMENSIONS |
|
With standard wheels and tyres, with fuel, oil and water |
|
Weight - 2WD/4WD |
2880 kg/3010 kg |
|
Overall Length - 2WD/4WD |
3.89 m/3.89 m |
|
Width - minumum |
2.06 m |
|
Overall Height - over exhaust |
2.52 m |
|
Wheelbase - 2WD/4WD |
2.29 m/2.29 m |
|
Turning Circle - less brakes 2WD/4WD |
2WD/4WD 8.55 m/9,75 m |
|
GroundClearance,under over drawbar |
381mm |
|
over front axle -2WD/4WD |
486 mm/395 mm |
|
CAPACITIES |
|
Fuel Tank |
70 litre |
|
