BOZOK 290 and BOZOK 275 model series Design simplicity, Large comfortable operator platform and Simple well-positioned mechanical controls are enabling the operator to easy to operate and easy access for servicing and maintenance.

BOZOK 290 and BOZOK 275 model series are equipped with Efficient Centre Shift Transmissions with 8+2 gearbox heavy-duty transmissions as standard.
BOZOK 290 and BOZOK 275 model series are equipped with power steering for easy maneuverability, spool valve for external hydraulics and oil immersed brakes for safety

BT GOLDPOWER equipped with new Highly efficient EURO Tier3-compliant 3-cylinder turbo, inter-cooler engines specified on the BT GOLDPOWER models built MORE POWER AND MORE TORQUE and require LESS DIESEL, and minimise Exhaust Emissions A product range combining performance, reliability, comfort and design. This is the great strength of BT GOLDPOWER tractors.

The BT GOLDPOWER series comes in three models and various variants from 50 to 67 Engine HP that designed for specific applications :

» For using in open field, For mowing, landscaping, tilling and transport, nothing’s more versatile than a BT GOLDPOWER Series tractors.
» MINIMAX model (narrow orchard) with a reduced width, horizontal exhaust and other features making it ideal for use in any confined space applications, such as vineyards and orchards or for working inside greenhouses and ideal for work in small-sized orchards.
» BAĞ-BAH聢E (ORCHARD) model (orchard) ideal for work in standard orchards.

PERFORMANCE

Rated Engine Power

ISO/TR14396
75 hp ( 54 kW )

Max. Torgue@1400 rpm
Max. PTO Power @ rated

275 Nm

engine speed

62.9 hp

ENGINE

Type

Perkins / 1104A-44

No. Cylinders

Injection

Direct

Capacity

4.4 litre

Air Cleaner

Dual, Dry Air Cleaner with
overbonnet centrifugal
pre - cleaner / Oil bath
air cleaner

Exhaust

Vertical

ELECTRICS

Alternator / Starter

50A/ 3.0kW

Lights

Headlights, Sidelights,
brake lights, direction
indicators,rear work lamp

Other

Horn, 7- pin trailer socket

CLUTCH

Type

Dual Clutch

Diameter

305 X 254 mm

TRANSMISSION

8 Forward 2 Reverse
Sliding Spur,

POWER TAKE OFF

Type

Dual Clucth, pedal operated

PTO speed

540 rev/ min @ 1685
engine rev / min or ground speedPTO

Shaft Diameter

35 mm ( 1.38 mm )

Number of Splines

HYDRAULICS

Functions

Draft, Position, and
response control

Max. Oil Flow

16.7 litre / min

Max.Pressure

207 bar

Max. Lift Capacity at links ends, link horizontal

2290kg

Lower Links

Cat 2 fixed ball ends
linkage check chains and
stabilisers

Drawbar

Swinging drawbar

STEERING

Type

Hydrostatic

REARAXLE AND BRAKES

Brake Type

Oil-Cooled, disc

Actuation

Mechanical, independent
or locked together

Parking Brake

Hand lever operated

Differential Lock

Mechanical actuation

OPERATOR AREA

Seat

Spring Suspension

Fender

Flat Top

Tool Box

With optional toolkit

INSTRUMENTATION

Gauges

Tachometer, fuel gauge,
temperature gauge

Warnings Lights

Electric charge, low engine
oil presure, direction
indicators, main beam,
filter,

STANDARDWHEELS AND TYRES

Fronts - 2WD
4WD

7.50 – 16
12.4x24

Rear - 2WD
4WD

16,9 – 30
16,9 – 30

WEIGHTS AND DIMENSIONS

With standard wheels and tyres, with fuel, oil and water Weight

2WD/4WD 2780 kg/3010kg

Overall Length

2WD/4WD3.60 m/3.89 m

Width - minumum Height

1.99 m Overall

over exhaust

2.52 m

over steering wheel

1.70 m

Wheelbase – 2WD/4WD m/2.29 m

2.06

Turning Circle - less brakes

2WD/4WD 7.20 m /9.75 m

GroundClearance,under over drawbar

381 mm

CAPACITIES

Fuel Tank

70 litre
