WE-260 BT GOLD POWER 4X2機型

產品目錄下載
BT GOLDPOWER equipped with new Highly efficient EURO Tier3-compliant 3-cylinder turbo, inter-cooler engines specified on the BT GOLDPOWER models built MORE POWER AND MORE TORQUE and require LESS DIESEL, and minimise Exhaust Emissions A product range combining performance, reliability, comfort and design. This is the great strength of BT GOLDPOWER  tractors.

The BT GOLDPOWER series comes in three models and various variants from 50 to 67 Engine HP that designed for specific applications :
» For using  in open field, For mowing,  landscaping, tilling and transport, nothing’s more versatile than a BT GOLDPOWER  Series tractors.
» MINIMAX  model (narrow orchard) with a reduced width, horizontal exhaust and other features making it ideal for use in any confined space applications, such as vineyards and orchards or for working inside greenhouses and   ideal for work in small-sized orchards.
» BAĞ-BAH聢E (ORCHARD)  model (orchard) ideal for work in standard orchards.
SPECIFICATION DESCRIPTION
ENGINE 260 BT GOLD POWER 4X2
Emission Stage IIIA
Make / Type BOZOK ENGINE / 1003D
Number of Cylinders / Aspiration 3 / Turbo Intercooler
Displacement 2990 cm3
Air Filter Dry Type
PERFORMANCE
Maximum Engine Power (ISO) 67 HP (49 kw)
Nominal Engine Speed 2200 d/d (rpm)
Maximum Torque 250 Nm / 1500 d/d (rpm)
CLUTCH
PTO Type Dry Dual Clutch
Disc Diameter 254 mm – 304 mm (10"-12")
IPTO Type Dry Single Clutch
Disc Diameter 305 mm (12")
STEERING
Type Hydrostatic
Maximum Steering Angle 50°
Turning Circle Without Braking 7000
TRANSMISSION
Type of Transmission Standard
Gear Option 8 Forward 2 Reverse
Optional Gear Option N/A
Drive Direct
Mechanical 4WD Engagement o
Differantial Lock Mechanical
Differantial Lock 29 km/h
POWER TAKE-OFF (PTO)
Mechanical Clutch (PTO) •
540 rpm PTO Speed @ 1790 rpm •
Independent Hydraulic Clutch ?/•
Ground Speed PTO ?/•
PTO Power (ISO) 56 HP @ 2250
BRAKES
Type

Disc Brakes
Pedals

Classic or Pendant Pedal
HYDRAULIC SYSTEM
Draft Control •
Position Control •
Accuracy Control •
Maximum Pump Flow 17-22 lt/dk (lt/min)
Maximum Pump Pressure 215 bar
Maximum Lifting Capacity 2000 kg
External Pump Flow 42lt/dk (lt/min) / 175 Bar
Spool Valve o / •
CAPACITIES
Fuel Tank 48 lt
Oil Sump 7.5 lt
Coolant 18 lt
Transmission & Hydraulics 2 lt
Steering 2 lt

MASSES AND DIMENSIONS
Total Mass with ballast (kg) 2716
Front Masses (kg) (6x20 Kg) – (聢ekili ağırlık 1x36 Kg)
Rear Masses (kg) (2x40 Kg)
A Front Axle Ground Clearance 550 mm
B Front Track Width 1380 mm
C Overall Width 1700 mm
D Rear Track Width 1330 mm
E Wheelbase 2050 mm
F Rear Overhang 845 mm
G Front Overhang 755 mm
H Overall Length 3650 mm
I Overall Height 2380 mm
J Hood-Top Height 1320 mm
L Folded ROPS Height 1468 mm
K Buffer Ground Clearance 310 mm
M Rear Tow ground Clearance 330 mm
  Front Tyres 6.50 -16
  Rear Tyres 14.9/13 - 28
