修牛蹄固定架

WE-Kipp Top

產品目錄下載

　

KIPP TOP BASIC - TECHNICAL DATA

Outer dimensions (mm)

2200/1900/1900 (L/W/H)
Recommended animal size 300-1000 kg life weight
Net weight 546 kg
Hitch quick coupling shaft Cat II
Lying area 1,10 x 1,90 m + head bow (0,55)= 2,45 m long
Cushions rubber mat + foam mat
drive 220V/1,8 kW electro-hydraulic
Surface galvanized
Serial equipment
  • Catching devise
  • Complete hardware from iron steel, galvanized
  • Complete hydraulic installation, ready for use, incl. drive motor and hydraulic pump
  • Complete electro-installation 220V, ready for use
  • Belt system complete
  • Lying area with rubber mat and shoulder cushions
  • 3-point-hitch cat II
  • Guiding bow
  • head bow swivelling
  • 4 quick snap leg holders
  • Operation manual
