FEATURES
Automatic self-priming system
Simple maintenance limited to checking fluid levels and filters
Liquid bath mechanical seal for dry-running and reduced maintenance
costs
Abrasion-resistant silicon carbide seal faces for trouble-free
performance
HIGH-VOLUME,
MEDIUM-HEAD, LARGE SOLIDS-HANDLING PUMP
The WE-CD300M pump offers flow rates to 5,990 US GPM
(1,360m³/hr) and has the capability of handling solids up to 3.7 in (95
mm) in diameter.
The WE-CD300M is able to automatically prime to 28 ft (8.5 m) of suction
lift. Automatic or manual starting/stopping available with mounted
control panel or optional wireless remote access.
Indefinite dry-running is possible with the exclusive Godwin liquid bath
mechanical seal design. Solids handling, dry running and portability
make the WE-CD300M the perfect choice for large volume water, sewage, or
sludge pumping applications.
AVAILABLE OPTIONS
Diesel engine driven, natural gas engine or electric motor driven
316 or CD4MCu stainless steel pump-end construction for high and low pH
applications
Highway trailer or skid mount, both incorporating integral overnight
running fuel tanks
Sound attenuated enclosure available
PrimeGuard engine controller with Field Smart Technology (FST)
|
