Paper Cup Making machine

　

　

　

　

　

　

　

　

Specification :

MODEL

GAP-90

GAP-90L

GAP-90XL

 GAP-90XLS

Product size

5oz ~ 16oz

22oz ~ 32oz
56oz ~ 130oz
56oz ~ 190oz

Speed (Actual)

90 –100 pcs/min

60 – 65 pcs/min
30~35 pcs/min
30 pcs/min

Mold change

Possible

Possible
Possible
Possible

Leister heater
(Side Seam)

220V X 3kw – 3ea

220V X 3kw – 3ea
220V X 3kw – 3ea
220V X 4kw – 3ea

Leister heater (Bottom)

220V X 3kw – 2ea

220V X 3kw – 2ea
220V X 3kw – 2ea
220V X 4kw – 2ea

Electric source power

220V, 3P, 50 / 60hz

220V, 3P, 50 / 60hz
220V, 3P, 50 / 60hz
220V, 3P, 50 / 60hz

Air compressor (Option)

15 hp
15 hp
20 hp
20 hp

Dimension
(W X L X H) mm

2,000 X 1,800 X 1,500 mm
2,350 X 2,350 X 1,700 mm
2,550 X 2,800 X 1,750 mm
2,800 X 3,000 X 1,800 mm

Weight

Appx. 2,800 kg
Appx. 3,800 kg
Appx. 5,000 kg
Appx. 7,000 kg



　
