吊杯式移植機

WE-2ZB-1自驅式移植機

WE-2ZB-1 tobacco transplanter





產品特點



Technical Specifications

  • 生產效率高人工移栽的4-6倍,勞動強度低
  • 功率強勁選用美國百力通(B&S)公司2.57KW汽油發動機。
  • 可靠性高開穴與移栽合為一體,動力消耗小,可靠性高。
  • 性能優越秧苗直立度好,成活率高
  • 適應性廣壟上、膜上均可實現移栽;行距、株距均可調整

  • High production efficiency----- production efficiency is 4-6 times more than that by manual transplanting and thus low labour intensity.

  • Strong Power-----Adopt American Briggs & Stratton(B&S) 2.57kW gasoline engine

  • High reliability -----digging holes and accomplish the transplanting at the same time,low power consumptionHigh reliability

  • Outstanding performance-----high perpendicularity rate and survial rate

  • Wide adaptability,  can plant both on ridge and film, row space and row pitch can be adjusted.











技術參數



Technical parameters

型號 WE-2ZB-1
結構型式 自走式
行走輪結構型式 橡膠輪
行走輪直徑(mm) φ400/φ540
輪軸距(mm) 1000
輪間距(mm) 1000-1100
外形尺寸(長×寬×高)(mm) 1800×1250×1110
配套動力 型號名稱 0831型四衝程汽油機
輸出功率(千瓦) 2.57
輸出轉速(r/min) 3600
栽植深度(mm) 40-80(可調)
栽植行數 1
栽植株距(mm) 300-750可調
栽植頻率(次/min) ≥35
秧苗條件 秧苗種類 缽苗(穴盤苗)
苗高(mm) 100-250

Model WE-2ZB-1
Structure walking
Walking wheel model rubber wheel
Walking wheel diameter  (mm) φ400/φ540
Wheelbase  (mm) 1000
Wheel gauge  (mm) 1000-1100
Outer measurement(L×W×H)  (mm) 1800×1250×1110
Matched power Model 0831 four-stroke gasoline engine
Output power  (kw) 2.57
Output rotating speed  (r/min) 3600
 depth  (mm) 40-80(adjustable)
Transplanting rows 1
Transplanting row pitch       (mm) 300-750 adjustable
transplanting frequency  (times/min) ≥35
Seedling requirements Seedling species Potted seedling(plug seedling)
seedling height   (mm) 100-250
