平底筒倉

Flat Bottom Silos

產品目錄下載



MODELS

4.58

9.17

13.75

18.33

22.92

32.08

5.35

9.93

14.51

19.10

23.68

36.66

6.11

10.70

15.28

19.86

24.45

41.25

6.88

11.46

16.04

20.63

25.97



7.64

12.22

16.81

21.39

27.50



8.40

12.99

17.57

22.15

30.55





Silo used for long-term storage of large quantities of grain

Our concrete base silos, either flat base silos or conical base silos, are used for long-term storage of large quantities of grain, seeds and granular products.


項目符號

Our flat bottom silos are manufactured with galvanized steel S350GD of high elastic tolerance and with Z600 minimum coating equivalent to 600 g/m2 of zinc.

項目符號

8,8 quality dichromate high tensile bolts in all of our product range.

項目符號

Washers with neoprene to ensure a waterproof seal.

項目符號

Galvanized reinforced exteriors, regardless of thickness, that provide excellent anti-corrosion qualities.

項目符號

Galvanized cross section roof structure on models with a diameter superior to 12,22 meters.
Our method for calculating thickness is more demanding than that established by standard EUROCODIGO 1.

項目符號

Stairs and platforms comply with regulation UNE-EN ISO 14122.
