TECHNICAL CHARACTERISTICS |
• Steel frame 6 mm thick, sturdy contruction
• Painted, rectangular tipping steel hopper
• N°2 Spreading discs with 4 stainless steel AISI 304 adjustable
vanes
• AISI 304 stainless steel flow control with 3 adjustable
openings
• Filtering grill
• Standard spring agitators
• 3 points linkage, 1st, 2nd Cat.
• Cardan shaft L = 800 mm |
Code |
Model |
S.07.01 |
SPW 600 |
S.07.10 |
SPW 800 |
S.07.20 |
SPW 1000 |
ACCESSORIES ON REQUEST
Code |
Description |
B.025 |
Stainless steel screw bolt set |
C.010 |
Spreader trolley "Standard Tray" pitch widh 1,35 metre |
C.015 |
Spreader trolley "Standard Tray" with adjustable pitch widh
from 1,2 to1,8 m. |
C.018 |
Cardan joint 1400 mm long, suitable for spreader on trailer |
C.040 |
Painted, double conveyor for localized fertilization on 2
rows |
C.041 |
Hot galvanized, double conveyor for localized fertilization
on 2 rows |
C.043 |
AISI 304 stainless steel double conveyor for localized
fertilization on 2 rows |
F.006 |
Double flexible cable L = 2,5 m. for remote control |
I.003 |
Double hydraulic opening |
I.004 |
Double hydraulic opening with micrometrical adjustment |
K.000 |
Lighting kit |
R.033 |
N° 3 small wheels for manual handling when dismounted |
T.004 |
Rain proof hopper cover |
T.056 |
Turning wheels application to partially relieve the tractor |
Z.007 |
Hot galvanized hopper |
Z.021 |
Hot galvanized hopper and frame |
TECHNICAL DATA
|
Model |
SPW 600 |
SPW 800 |
SPW 1000 |
Spreading system |
Double spinner disc |
Moving machine |
Mounted |
Hopper volume |
605 litres |
790 litres |
985 litres |
Application rate |
3,5 he / h |
Overall dimensions ( WxLxH ) |
163x126x96 cm. |
163x126x104 cm. |
163 x126 x112 cm. |
Machine mass empty |
160 kg |
167 kg |
182 kg |
Spreading width |
16 - 24 m. |
Minimum power tractor |
50 HP |
55 HP |
80 HP |
Cardan shaft revolution |
540 rpm |
Suitable fertilizer type |
Chemical granular, powdered, pellet fertilizers |
|
