牧草切碎收穫機

FCT 1360-1460機型

產品目錄下載


規格介紹

Model

型號

FCT 1360

FCT 1460

Tractor, min. (kW/HP)

拖拉機馬力(最小值)

103/140

147/200

Tractor, max. (kW/HP)

拖拉機馬力(最大值)

165/225

206/280

PTO-type, standard

PTO類型,規格

1 3/4 - 20 splines

1 3/4 20 splines

PTO (RPM)

PTO(轉速)

1000

1000

Rotor width

轉動寬度

900 mm

900 mm

Number of knives

刀片數

40

40

Cutting length, theoretical (mm)

切草長度

7-15-(30)

6-8-12-16- (32)

Transport width (m)

運輸寬度

3,53

3,57

Pick-up (m)

取草工作寬度

3,10

3,10

Maize unit

榖裝置

3-row

-

Metal detector

金屬探測器

-

標準

Wheel standard

輪胎規格

19/45x17

500/50-17

Reverse mechanism

反向機制

液壓

液壓

Oil outlets

油口

1 DA

1 DA

Weight

機器重量

3600

3750
