超大水平進料碎木機

WE-3680 XP 型號

產品目錄下載




FEATURES:
  • 30’ folding discharge
  • Fifth Wheel or Pintle
  • Hydraulically activated screen that opens to reduce damage to the mill from debris
  • Numerous tooth/screen combinations
  • Radio remote control /w tether


Specifications

Standard Metric
Capacity 35 in 88.90 cm
Production Capacity 300-500 yph
Opening 60 in  x  35 in 152.40 cm  x  88.90 cm
Width 115 in 292.10 cm
Height 159 in 403.86 cm
Length 468 in 1188.72 cm
Weight 59000 lbs 26761.95 kg
Fuel Tank 500 gl 1892.71 l
Hydraulic Tank 140 gl 529.96 l

OPTIONS:
  • Optional chipping drum
  • Optional mulch coloring system
  • Optional proportional feed system
  • Optional 30-tooth cuttermill
  • Optional Air Compressor
  • Optional Overband Magnet
  • Optional shingle grinding package
