Peanut Combine Harvester

Movice ( Video)  525 Movice ( Video) 43



Model : 43

  Specification & Description :

Model :

 43

Bulk / Bag

Machine measurement overall length ( mm )  4300
overall width  ( mm )  2100
overall height ( mm ) 2650
machine Weight Kg 2850
Engine Model  water cool, 4 stroke, 4 cylinder, diesel
Displacement ( CC ) 2000
house power / Rotation  ( PS / rpm ) 43 / 2800
Fuel tank ( liter ) 40
Start type  electric
Transportation Crawler ( width x length )  ( mm )  400 x 1390
Crawler base ( mm )  1000
average ground pressure  ( kg / cm2 ) 0.2
transmission HST
speed  ( M / second ) 0.79 -2.39



*********************************************************************************************

Model : CF 525

 Specification & Description :

Model  CF 525
working efficiency @ @
Machine measurement overall length ( mm )  4,000
overall width  ( mm )  1,950
overall height ( mm ) 2,600
Machine Weight Kg 2,670
Engine Model  3TN100-RBC  diesel engine
type  water cool, 4 stroke vertical cylinder
Displacement (CC ) cylinder /bore x stroke 2.591 CC  /   ( 3 x 100 x 110 )
house power  / Rotation 60 / 2600
injection Direct type
Fuel tank ( liter ) 60
Transportation Crawler ( width x length )  ( mm )  450 x 1485
Crawler base ( mm )  1025
average ground pressure  ( kg / cm2 ) 0.217
clearance ( mm )  190 -285
transmission HST
speed  ( forward )  M /S /  ( reverse )  M/S 0-0.81 /   0-0.135

@
